Linear Plastic Cup Filling and Sealing Machine

This machine id designed for packing the plastic cup and with min dia50mm, max dia 95 mm. any one size working machine. Filling and sealing done by machine we have put bulk glass manually in machine and it will pick one by one. Also, single peas of foil to be use. For following features.

HOW WORKS NO. OF 6 STATIONS

Cup Dropping Station

• Bulk cups are placed at the top of the assembly.
• Pneumatic cylinder picks and drops cups one by one into pockets.
• Cups move forward to the filling station.
• If 4 cups are missing, machine stops and shows an error.

Cup Filling Station

• Sensor detects 4 cups before filling starts.
• Fills cups with preset quantity.
• Filling accuracy of ±5%.
• Volumetric or servo filling based on product.
• 150–200 L storage tank with auto cut-off pump.
• Overflow drainage and easy cleaning system.

Cup Foil Dropping Station

• Bulk foil placed with weight for smooth feeding.
• Cylinder picks foil one by one.
• Main assembly rotates 180° to place foil on cup.

Cup Foil Sealing Station

• Heated brass sealing jaws provide strong sealing.
• Individual temperature controller for each head.
• Separate spring-loaded jaws for pressure accuracy.

Cup Removing Station

• Sensor-based system removes cups smoothly.
• No cup falling or tilting during removal.
• Cups are transferred safely onto conveyor.

We are distinguished manufacturer and exporter of construction machines and packaging equipment. Our wide product range is well-known for its various features like durability, high tensile strength, easy operation, low maintenance and high performance. We use premium quality raw material, which is procured only from reliable vendors for manufacturing our product range. Our product range is catering to the business needs of various industries including pharmaceutical, chemical, food & beverages and construction industry.

Technical details :

No. of filling head	: Multiple head
No. of sealing head	: Multiple head
Assembly type	: Linear
Power supply	: 6.5kw
Speed	: As per head
Voltage	: 220V
Heat power	: 500 W
Frequency	: 50-60 Hz
Temp. controller	: 0 TO 400 C
Machine capacity	: As per head
MOC	: Stainless steel 304
Pneumatic cylinder	: genetic
Pouch dropping	: Via vibrator
Automatic foil feading	: Available
Air compressor	: 5 HP (From client side)
Driven type	: Electric
Suitable for	: oil, milk, water, juice

No. of station:

• Cup dropping station
• Cup filling station
• Cup foil dropping station
• Cup foil selling machine
• Cup removing station
• Conveyor

4 Head Linear Cup Filling and Sealing Machine
