Liquid Pouch Filling Machine Manufacturer

Automatic Pouch Filling Machine in Gujarat

A Liquid Pouch Filling Machine Manufacturer is a company that focuses on designing and manufacturing the high performance machine that would fill liquids in the pouches in a disciplined and hygienic manner. These machines are very common in packaging water, milk, juice, oil, sauces among other liquid products in the food and beverage, dairy, pharmaceutical, chemical and cosmetic industries. The machines are constructed using modern technology and stainless steel, therefore, they are accurate to fill, wastage is limited, and they are fast to produce. They are designed to have easy controls, automatic sealing mechanisms and adjustable settings to deal with various pouch sizes and viscosity of liquids. Liquid pouch filling machines are known by their durability, low maintenance, and stable performance, making them a better choice to use in the small, medium, and large-scale manufacturing units when in need of an effective packaging solution.

Manufacturer of liquid filling machine

Specification :

Feeding head : Volumetric pump operated filling system
Packing range : 5-50 ml
Production speed : 40-50 pouches per min (depends product)
Machine control system : Electronic controls
Film width : up to 210 mm. approx.
Film thickness : 40 to 80 microns
Sealer heating system : PID controlled
Filling accuracy :+/- 1% (Depends on product)
Inner core dia. of film roll : 70mm
Outer dia. of the film roll :up to 350mm
Pouch style :three side / four side sealing
Pouch width :up to 100mm
Pouch length :up to 165mm
Compressed air pressure :N/A
Air consumption :N/A
Power consumption :1KW /HOUR
Peak power :3 kw
Power requirement :single phase, 220V, 50 Hz
Film guard mechanism :N/A
Pouch counter :provided
Photo cell :provided
Machine dimension in MM :1500(H) x 450(W) x 450(Depth)
Net weight :360 kg’s (Approx.)

Features:

  • • Compact and space-saving design
  • • Hygienic stainless-steel construction
  • • Easy to operate and clean
  • • Adjustable filling volume via touch screen (in automatic version)
  • • Integrated pouch cutting and sealing
  • • Option for date/batch coding
